Especificação
Elétrico | Voltagem nominal | 12,8 V |
Capacidade nominal | [email protected] | |
Energia | 3840Wh | |
Resistencia interna | ≤35mΩ | |
Ciclo da vida | 2000-6000 Cycles @ 0.2C Charging/Discharging ,Until 70% Capacity | |
Auto-descarga | ≤3,5% por mês a 25 ℃ | |
Carregamento Padrão | Max.Charging Voltage | 14,0 ~ 14,6V |
Modo de Carregamento | Na temperatura de 0 ℃ ~ 45 ℃, carregada a 14,6 V a uma corrente constante de 0,2 C e, em seguida, mudou continuamente com tensão constante de 14,6 V até que a corrente não fosse mais do que 0,02 C | |
Corrente de Carga | 100A | |
Corrente de carga máxima | 100A | |
Descarga Padrão | Corrente de descarga | 100A |
Máx. Corrente Contínua | 100A | |
Max.Pulse Current | 200A (<3S) | |
Tensão de corte de descarga | 10.0 | |
Condição operacional | Temperatura de carga | 0 ℃ a 45 ℃ (32 ℉ a 113 ℉) @ 60 ± 25% de umidade relativa |
Temperatura de Descarga | -20 ℃ a 60 ℃ (-4 ℉ a 140 ℉) @ 60 ± 25% de umidade relativa | |
Temperatura de armazenamento | 0 ℃ a 45 ℃ (32 ℉ a 113 ℉) @ 60 ± 25% de umidade relativa | |
Resistência à Pó de Água | IP55 | |
Estrutura | Célula e formato | 4S1P, prismatic |
Invólucro | Plástico | |
Dimensão (L * W * H * TH) | 522*270*217*217mm | |
Peso | Approx. 27.5Kg | |
terminal | M8 |
Can add LCD fuel gauge.
Can add Control switch.
Can add Coulomb lamp display.
Can add USB connector.
◆ Utilizando a tecnologia de célula de fosfato de ferro lítio, segurança superior, milhares de ciclos, 100% DOD, em condições normais.
◆ Proteção automática integrada para sobrecarga, descarga excessiva, sobrecarga de corrente e temperatura excessiva.
◆ Livre de manutenção.
◆ Balanceamento celular interno.
◆ Peso mais leve: Cerca de 40% ~ 50% do peso de uma bateria de chumbo-ácido comparável.
◆ Pode ser carregada usando a maioria das cargas de chumbo-ácido padrão (conjunto).
◆ Faixa de temperatura mais ampla: -20 ℃ ~ 60 ℃.
◆ Suporte para expansão de aplicativos em Série (até 51,2V) e dois em paralelo.
Nossa fábrica
Embalagem e envio
Perguntas frequentes
Q1. Is it OK to print my LOGO on the product?
A. Sim. Por favor, informe-nos formalmente antes de nossa produção e confirme o projeto com base em nossa amostra.
Our factory supports Customized: case, size, battery structure, logo, packaging etc.
Q2. Posso ter um pedido de amostra?
A.Yes, we welcome sample order to test and check quality.
Low MOQ, 1pc for sample checking is available.
Q3:Which product is hot sale in your company?
A: LiFePO4 battery 24Ah,50Ah,100Ah,200Ah,280Ah,300Ah; 12V,24V, 48V LiFePO4 battery pack and so on.
Q4. What about the lead time?
A. Sample needs 3-7 days, mass production time needs 7-20 days, it depends on order quantity.
Q5. Como proceder com um pedido?
A. Firstly let us know your requirements or application. Secondly, We quote according to your requirements or our
suggestions.Thirdly customer confirms the samples and places a deposit for formal order. Fourthly We arrange the production.
Q6.Which certificates do you have?
A: Nós temos CE / FCC / ROHS / UN38.3 / MSDS ... etc.
Q7.How about warranty?
A:3-5 year warranty
Q8: Are these battery packs compatible with my inverter?
A: Yes, Sir. Our battery pack is compatible with most brands of inverters on the market.
Contact us and let me tell you more.
Q9. How do you ship the goods and how long does it take to arrive?
A.It usually takes 5-7 days to arrive. Train and Airline and Sea(DDP) shipping is also optional.
Q10: How do I know whether you've shipped my order or not?
A: Tracking No. will be offered as soon as your order be shipped out. Before that, our sales will be there to check the packing
status, photo you the done order and let you know the forwarder picked it up.
